LUBRICATION OF THE STRAIGHT LINE RIPSAW
(Based on a 40 hour week)
D
A
I
L
Y
W
E
E
K
L
Y
M
O
N
T
H
L
Y
6
M
O
N
T
H
S
Feature
Type of lubrication
Fill the oil level in the reservoir for the feed chains.
SAE 30 wt. oil
X
Fill the oil cups for the arbor assembly.
X
Grease the drive cam shaft bearing.
Good Grade Bearing Grease
X
Oil the pressure bar oil ports (4 locations).
SAE 30 wt. oil
X
Check the oil level in the drive gear box.
Exxon Spartan EP150
X
Change the oil in the drive gear box.
Exxon Spartan EP150
X
