Table travel in X axis

12"

Table travel in Y axis

4"

Nominal knife bevel angle adjustment

35° to 65°

In/out adjustment of the grinding spindle

2"

Relief grinding angle adjustment

± 20°

RPM of the grinding spindle

500 - 3000

HP of the arbor motor

1 ½

Maximum cutterhead diameter

12"

Minimum cutterhead diameter

4"

Maximum cutterhead length

12"

Submersible coolant pump

w/ 15 Gallon tank

Dresser location

On the table

Micro-adjustable diamond dresser

Standard

X & Y table lock

Standard

Grinding wheel provided

6

Location of the template holder

Right side

Point of Origin grinding

Standard

Stylus sizes

2, 3, 4, mm, Vee angled

Maximum diameter of the grinding wheel

225 mm

Minimum diameter of the grinding wheel

160 mm

Grinding wheel bore

60 mm

Template X axis adjustment

mm micro adjust

Template Y axis adjustment

mm

Arm rest

Standard

Machine lamp

Standard

AC inverter drive

Standard

Axial constant grinding

Standard

Additional grinding wheel hubs

2

Grinding arbor included standard (specify diameter)

1

Coolant jets above and below tool rest

3

Size (with full table travel)

45"L x 85"W x 57"H

Weight

1400 lbs.
