• Tilting feed system.
  • Tilting right spindle.
  • Grooved bed guide system.
  • Pneumatic chipbreakers.
  • Damp lumber feed package.
  • Additional lower and upper powered feedrolls.
  • Production monitoring system.
  • Hydraulic feed drive.
  • 6" minimum cutting circle.
  • Adjustable outfeed table.
  • Automatic cutterhead jointers.
  • Split top holddown shoe.
  • Stellite hardened beds & guides.
  • Chrome plated beds & guides.
  • Horizontal spindle outboard bearings.
  • Pneumatic holdover rolls.
  • Pneumatically controlled enclosure door.
  • Extended infeed table.
  • Electronic spindle brakes.
  • Material Handling.
  • Electronic digital readouts.
  • Magazine infeed loading hopper.
  • Hydraulic feed (up to 350 fpm) with larger feedrolls.
  • Jointer stone setup stand.
  • Sawing and splitting module.


D5000 Specifications

Bottom spindle HP
15 HP Standard, 20-50 HP Optional
Right spindle HP
10 HP Standard, 15-20 HP Optional
Left spindle HP
10 HP Standard, 15-25 HP Optional
Top spindle HP
15 HP Standard, 20-50 HP Optional
Universal spindle HP
10 HP Standard, 15 HP Optional
Working width
9-1/4"
Working height
4-1/2"
Cutterhead swing (except 1st bottom)
10"
Cutterhead swing (1st bottom)
8"
Minimum cutting circle
6"
Feed System
A.C. Frequency Inverter for up to 200 FPM
Chainless Cardan drive system
